11.1Troubleshooting

Thetroubleshootinginformationprovidespossible

causesandcorrectiveactionrequiredforcommon

problemsassociatedwithmarineelectronics

installations.

AllRaymarineproductsare,priortopackingand

shipping,subjectedtocomprehensivetestand

qualityassuranceprograms.However,ifyou

experienceproblemswiththeoperationofyour

productthissectionwillhelpyoutodiagnose

andcorrectproblemsinordertorestorenormal

operation.

Ifafterreferringtothissectionyouarestillhaving

problemswithyourunit,pleasecontactRaymarine

TechnicalSupportforfurtheradvice.

11.2Performingasystemreset

Note:PerformingaresetwillnotresetMMSIand

ATISIDnumber.

FromtheMaintenancemenu:Menu>Set-up>

Maintenance.

1.SelectSystemreset.

2.SelectYes.

Thesystemisnowresettofactorydefaults.

Note:Performingtheresetwilldeleteallcontacts

inyourphonebookandresetalluseroptions.

Ray50/Ray60/Ray70
