INSTALLATION & OPERATING

INSTRUCTIONS

Gas-Fired

Pool & Spa

Heater

Catalog No. 6000.59U Effective: 10-06-10 Replaces: 06-10-10 P/N 241236 Rev. 22

WARNING: If these instructions are not followed exactly, a fire or explosion may result

causing property damage, personal injury or death.

WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor's phone. Follow the gas sup-

plier's instructions.

• If you cannot reach your gas supplier, call the fire department.

Installation and service must be performed by a qualified installer, service agency or

the gas supplier.

This manual should be maintained in legible condition and kept adjacent to the heater or in a safe place for future

reference.

Atmospheric Models

206A, 266A, 336A & 406A

Lo NOx Models

207A, 267A, 337A & 407A

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of

this or any other appliance.
