16
4 PIPE
DIAMETERS
MAX.
4 PIPE
DIAMETERS
MAX.
4 PIPE
DIAMETERS
MAX.
Models 926-1826 with H-Bypass
BLENDED WATER TEMPERATURE
(THERMOMETER AT HEATER INLET)
HEATER OUTLET TEMPERATURE
THERMOMETER
HEATER THERMOSTAT
RECOMMENDED FIELD INSTALLED
ISOLATION VALVES FOR SERVICE
TI
To
Tc
Piping Configurations for Raytherm Commercial Pool Heaters
