17
BLENDED WATER TEMPERATURE
(THERMOMETER AT HEATER INLET)
HEATER OUTLET TEMPERATURE
THERMOMETER
HEATER THERMOSTAT
RECOMMENDED FIELD INSTALLED
ISOLATION VALVES FOR SERVICE
TI
To
Tc
4 PIPE
DIAMETERS
MAX.
4 PIPE
DIAMETERS
MAX.
4 PIPE
DIAMETERS
MAX.
Models 2100 thru 4001 with H-Bypass
Piping Configurations for Raytherm Commercial Pool Heaters
