Transmission of Temperature Lines
16 Rev. B4 Aug 2019 MP150 Protocol
• [snapshot/line counter]: counts the lines in burst mode and the snapshots in snapshot mode
• [background temperature / voltage input]: If background temperature compensation via
voltage input is configured then it contains the background temperature (as integer in °C)
calculated from the voltage, otherwise it contains the voltage.
• [error bits]: error bits (see section 3.4 Error Handling, page 11)
4.4.6.3 Line Mode 13hex
LM = 13hex extends LineMode 11hex in the traditional field [Sectorinfos]. The first 6 bytes remain as in
Line LineMode 11hex, they get extended by additional bytes:
Sectorinfos = 2 Bytes for snapshot/line counter
2 Bytes for background temperature / voltage input
2 Bytes for error bits (see section 3.4 Error Handling, page 11)
2 Bytes for result sector/zone 0
2 Bytes for result sector/zone 1
2 Bytes for result sector/zone 2
2 Bytes for result sector/zone 3
2 Bytes for result sector/zone 4
2 Bytes for result sector/zone 5
2 Bytes for result sector/zone 6
2 Bytes for result sector/zone 7
2 Bytes for result sector/zone 8
2 Bytes for result sector/zone 9
• [snapshot/line counter]: counts the lines in burst mode and the snapshots in snapshot mode
• [background temperature / voltage input]: If background temperature compensation via
voltage input is configured then it contains the background temperature (as integer in °C)
calculated from the voltage, otherwise it contains the voltage.
• [error bits]: error bits (see section 3.4 Error Handling, page 11)
• [result sector/zone N]: temperature that was calculated in the zone/sector, the format is define
by the data mode (DM) command
