RayTek LineScanner MP150 User Manual

Appendix
40 Rev. B4 Aug 2019 MP150 Protocol
Description
Code
Parameter
Explanation
Factory default
Sector Top for an analog
output of the internal current
output and the external
modules
ST
n d
Temperature maximum of sector
n = 1…9: sector/zone number
n = 0: digital Interface
d: temperature in °C
result of GRF
command
Trigger Bottom
TB
n d
Alarms when result is less than or equal
to this value
n = 0…9: sector/zone number
d = temperature in °C
The alarm is given to the internal and
external outputs.
result of GRB
command
Trigger Top
TT
n d
Alarms when Result is greater than or
equal to this value
n = 0…9: sector/zone number
d = temperature in °C
The alarm is given to the internal and
external outputs.
result of GRF
command
Zone Delay
ZD
ndddd
Zone Start Delay Time
Is not used at all and replaced by the
ZP-command. (It will give an answer for
backward compatibility.)
0
Zone Width
ZW
ndddd
Time of the Zone
Is not used at all and replaced by the
ZP-command. (It will give an answer for
backward compatibility.)
0
Zone Mode
ZM
nd
Only defined for sector/zone: n = 0
n = 1..3: for backward compatibility
d = 0: Zone Mode off
d = 1: Zone Start with a timer
d = 2: Zone Start by trigger
d = 3: Zone Start with a temperature
level
0
Zone Trigger
ZT
ndddd
Crossing Temperature in °C for Zone
Mode 3
Only defined for sector/zone: n = 0
n = 1..3: for backward compatibility
dddd in °C
GRB
Zone Cycle
ZZ
ndddd
Zone Cycle in Zone Mode 1
Only defined for sector/zone: n = 0
n = 1..3: for backward compatibility
dddd : time in tenth of a second
0
Error Mode
EM
nd
reaction of current outputs in case of
scanner error
n=1..3: sector/interface
d=0: hold last value
d=1: set minimum
d=2: set maximum
0
