Gyro Compass Standard 22 NX
2 Operation
Edition:001 9 10000000015
2. Check the gyro compass after 30 minutes.
► The gyro compass has switched over into the settling stage.
► The display shows the display page Heading (Settling).
Fig. 2: Display Page: Heading (Settling)
Note
No valid NMEA heading and NMEA Rate of Turn (RoT) is distributed during the settling
stage.
Note
The settling of the gyro compass takes approximately 3 hours.
3. Check the gyro compass after 3 hours.
► The gyro compass is full operational.
► The display shows the display page Heading (Available).
► The gyro compass distributes the heading to all connected systems.
