Page #31 background imageLoading...
Page #31 background image
Gyro Compass Standard 22 NX
3 Faultfinding
Edition:001 21 10000000015
3  Faultfinding
3.1  Faultfinding Table
Failure Error Code Possible Cause Remedy
Errors
Display shows
the error Inductive
Transmission faulty.
EL01
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error System Volt-
age on Sensor PCB
faulty.
EL02
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Encoder Volt-
age faulty.
EL03
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Interface Volt-
age faulty.
EL04
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Encoder faulty.
EL05
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Cable connection in
the gyro compass is
disturbed.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Internal CAN
Dialogue faulty.
EL06
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Cable connection
between Outer
sphere and sensor
PCB is disturbed
Call the Raytheon
Anschütz service for
repair.
Tooth belt is defec-
tive.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Follow-Up Sys-
tem faulty.
EL07
Step motor out of
operation.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Support Liquid
error.
EL08
Support liquid level
is too low.
Call the Raytheon
Anschütz service for
repair.
