Raytheon Anschütz Standard 22 NX User Manual

Gyro Compass Standard 22 NX
2 Operation
Edition:001 11 10000000015
Area / Element Description
Heading Shows the heading of the vessel
Stage
Shows the stage of the gyro compass
Note: The different stages are descrobed in
the following table.
Spd
Shows the speed of the vessel
Note: If the log is not available, no speed is
displayed.
Lat
Shows the latitude of the vessel
Note: If the GNSS is not available, no lati-
tude is displayed.
Stage Description
OFF
The gyrosphere of the gyro compass is not
in function.
No heading is available.
Note: For detailed information of the dis-
played failures, see chapter 3.1.
Heating
The gyro compass is in the heating stage.
The current temperature is displayed.
No heading is available.
Settling
The gyro compass is in the settling stage.
No valid heading is available.
Available (cor.)
The gyro compass is fully operational.
The automatic speed error correction is in
function.
Available (uncor.)
The gyro compass is operational.
The automatic speed error correction is not
in function.
Note
If position and speed input from GNSS and log is not available, the automatic speed error
correction is not in function.
Note
If the gyro compass detects an internal failure and the failure is displayed to the user, no
heading is displayed and transmitted to connected devices, see Fig. 5.
