Razor DRIFT RIDER User Manual

5-1
5-2
10
REPAIR AND MAINTENANCE
Hub Motor Replacement
Required Tools: Phillips screwdriver.
1 Power switch in OFF position.
Turn power switch “OFF” before beginning repair or maintenance:
• Read the instructions
• Remove charger plug
• Turn the power switch off
• Secure the unit under repair
• Exercise caution around
exposed parts
• Contact Razor customer
service if unsure about any
repair or maintenance
2 Remove flag and rotate onto handlebars.
3 Remove six (6) Phillips head screws using the
Phillips screwdriver.
4 Remove front battery cover.
5 Disconnect motor cables.

Razor DRIFT RIDER Specifications

General

Maximum speed	14 km/h
Product color	Black, Red
Maximum load weight	65 kg
Recommended age (min)	9 yr(s)
Motor power	100 W
Battery life	40 min
Battery voltage	22 V
Number of batteries supported	1
Manual	Yes

Weight and Dimensions

Depth	956 mm
Width	602 mm
Height	596 mm
Weight	24350 g
