Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer Service
contact information is listed at the back of this manual.
ASSEMBLY AND SET-UP
1 Remove the four (4) coupling
bolts from the front fork using a
5 mm Allen wrench and a 10 mm
wrench.
2 Insert the wheel assembly into
the front fork and align holes.
When installing the wheel, make
sure the letter “F” and arrow
(located on the side of the wheel)
are facing the direction as shown
above.
Attaching the Front Wheel
Required Tools: 5 mm Allen wrench and 10 mm wrench
3 Reinsert the coupling bolts
through the front fork and tighten
securely.
Attaching the Seat
Required Tools: Two (2) 5 mm Allen wrench
1 Using two (2) 5 mm Allen
wrenches, remove the four (4)
coupling bolts from the frame.
2 Align the four (4) holes in seat
with the four (4) holes in frame.
Insert the coupling bolts through
the top and bottom of the frame.
3 Tighten the coupling bolts using
two (2) 5 mm Allen wrenches.
