Razor RipRider 360 - Product Parts

6
6-2
6-3
6-1
6-4
6-5
7
7-1
1
3
4
4-1
2
2-1
5
6
Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer Service
contact information is listed at the back of this manual.
Keep your RipRider 360˚ Caster Trike rolling for years with genuine Razor parts. Visit our website to purchase replacement parts.
(Specifications subject to change without notice.)
RIPRIDER 360° CASTER TRIKE PARTS
1. Handlebar Grip (x2)
2. Front Fork
2-1. Front Fork Coupling Bolts (x4)
3. Front Cover
4. Steering Bolt
4-1. Lock Nut
5. Front Wheel w/ Pedals and Cranks Complete
6. Rear Wheel Complete (x2)
6-1. Rear Wheel Cover (Upper/Lower)
6-2. Spring Washer
6-3. Caster
6-4. Axle Bolts
6-5. Wheel
7. Seat
7-1. Seat Coupling Bolts (x4)
