UNC100 Axiom Hardware Manual V1.1 RBH Access Technologies Inc.
Page 25 of 25
UNC100 Specification
Controller Power Requirements
12 – 14vdc
Current Consumption
250mA
Processor
32 bit micro controller
Memory
2MB
UNC-NET Connections
15
RC-2 Connections
4 (3 + 1 internal)
IOC-16 connections
16
UNC-NET Communication speed
156250 baud
DNET Communication speed
38400 baud
HOST Ethernet speed
10/100 TCP/IP Ethernet, RS485 4 wire
HOST RS485 Speed
9600, 38400, 57600, 115200 baud
Clock/RAM backup battery
3v Lithium battery CR1632
Real Time Clock
Built-in as standard
Watch Dog Circuit
Built-in as standard
Board Dimensions
H 5 ½ in x W 5 in (14 x 12 ½ cm)
Operating Temperature
0 to 70C (35 - 150F)
Operating Humidity
20 to 85% RH (non-condensing)
Cable Specification
Circuit Function
Cable type
Length
PC To Controller (Ethernet)
CAT5 communications cable
323 feet (100 meters)
PC To Controller (RS485)
Twisted pair, shielded, stranded
18 to 22 AWG
4000 feet (1200 meters)
UNC-NET
Twisted pair, shielded, stranded
20 to 22 AWG
2500 feet (750 meters)
D-NET
1 twisted pair, shielded, 20 to 22
AWG
3000 feet (900 meters)
Reader
20 to 22 AWG, 6 or 8-conductor,
stranded, shielded (not twisted)
500 feet (150 meters)
Input / Output Port Circuit Loop
2-conductor, 20 to 22 AWG
1000 feet (300 meters)
