Controller Addressing
Use DIP switches 1, 2, 3, and 4 to select the controller address. The address is binary coded and the
switch settings for all fifteen possible addresses are given below.
Controller Addressing
Switch 1
Switch 2
Switch 3
Switch 4
Address
Off
Off
Off
Off
Clear Memory
On
Off
Off
Off
1 (Master)
Off
On
Off
Off
2 (Slave)
On
On
Off
Off
3 (Slave)
Off
Off
On
Off
4 (Slave)
On
Off
On
Off
5 (Slave)
Off
On
On
Off
6 (Slave)
On
On
On
Off
7 (Slave)
Off
Off
Off
On
8 (Slave)
On
Off
Off
On
9 (Slave)
Off
On
Off
On
10 (Slave)
On
On
Off
On
11 (Slave)
Off
Off
On
On
12 (Slave)
On
Off
On
On
13 (Slave)
Off
On
On
On
14 (Slave)
On
On
On
On
15 (Slave)
