RBI DOMINATOR Series User Manual

Fi d b b il & h B il M l
Fi
nne
d
co
pp
er tu
b
e gas
b
o
il
ers
&
water
h
eaters –
B
o
il
er
M
anua
l
47
F
F
Model Size with Item Quantities Below
Ref # Name of Part Part # 300 400 600 750 900 1050 1350 1500 1950 2100
35 O Ring, Inlet/Outlet & Return Headers 06-0001 20 20 20 20 20 20 20 20 20 20
36
Stud, Inlet/Outlet & Return Headers ASME 57-0223 12 12 12 12 12 12 12 12 12 12
Stud, Inlet/Outlet & Return Headers NonASME 57-0225 12 12 12 12 12 12 12 12 12 12
37
Nut, Inlet/Outlet & Return Headers ASME 57-0492 12 12 12 12 12 12 12 12 12 12
Nut, Inlet/Outlet & Return Headers NonASME 57-0491 12 12 12 12 12 12 12 12 12 12
38
Return Header, Bronze
01-0018S 1111111111
Return Header, Cast Iron
01-0023S 1111111111
39
Inlet/Outlet Header, Bronze
01-0019S 1111111111
Inlet/Outlet Header, Cast Iron
01-0022S 1111111111
40
Blower, Fasco 7062 12-0013 1 1 1
Blower, Fasco 7083 12-0014 1122222
41 Combustion Air Damper Assembly
70-2818 1 1 1
70-2819 1122222
42
Low Pressure Switch (.30 WC) 14-0059 1111122222
High Pressure Switch (.58 WC) 14-0058 1111122222
43
High Limit, L4008E, (DB) 14-0112 1111111111
High Limit, L4008E, (DW) 14-0105 1111111111
NS Operator, T6031A (pool heater) (Canada Only ) 14-0003 1111111111
44
Firing Valve, 3/4” 11-0461 1 1
Firing Valve, 1” 11-0456 1112222
Firing Valve, 1 1/4” 11-0457 2
NS Manual Pilot “B” Valve 11-0031 1111111111
45
Main Gas Valve, VR8305 11-0087 1 1
Main Gas Valve, V8944B, 1” 11-0171 1112222
Main Gas Valve, V8944B, 1 1/4” 11-0172 2
46
Safety Valve, V48A, 1” 11-0371 1 1 1
Safety Valve, V48A, 1 1/4” 11-0364 1 1 1
Safety Valve, V48A, 1 1/2” 11-0365 1 1
47 Pilot Valve, VR8205Q 11-0086 1111111111
48
Manual Shut O Valve, 1” 11-0456 1 1 1
Manual Shut O Valve, 1 1/4” 11-0457 1 1 1
Manual Shut O Valve, 1 1/2” 11-0458 1 1
50
BTC Staging Control, 2 Stage 14-0306 11111
BTC Staging Control, 4 Stage 14-0307 11111
NS
10K Temperature Sensor 14-0325 3333333333
Outdoor Sensor 14-0319 1111111111
51 Flame Sensor, UTC 1003 Ignition Module 16-0059 1111111111
NS Alarm Board, (CSD-1) 16-0023 1111111111
52 Spark Generator 16-0045 1111111111
53
Transformer, 50 VA 15-0007 11111
Transformer, 75 VA 15-0008 11111
NS Pump Time Delay Relay 15-0120 1111111111
NS Low Gas Pressure Switch (Manual Reset) 11-0410 1111111111
REPAIR PARTS (CONTINUED)
