RBI FUTERA XLF Series User Manual

MODBUS COMMUNICATIONS HeatNet Control V3
Page 106
Figure 64 MODBUS Input Variables (Read Only)
Address
Name
Raw Data
Type
Scale
Description
Valid Values/Range
30135
Boiler04CyclesLow16
Example
Boiler01Cycles =
(Boiler01CyclesHigh16 * 65536) +
Boiler01CyclesLow16
Boiler01 = Master
Boiler02 = Member01
…
Boiler16 = Member15
30136
Boiler05CyclesHigh16
30137
Boiler05CyclesLow16
30138
Boiler06CyclesHigh16
30139
Boiler06CyclesLow16
30140
Boiler07CyclesHigh16
30141
Boiler07CyclesLow16
30142
Boiler08CyclesHigh16
30143
Boiler08CyclesLow16
30144
Boiler09CyclesHigh16
30145
Boiler09CyclesLow16
30146
Boiler10CyclesHigh16
30147
Boiler10CyclesLow16
30148
Boiler11CyclesHigh16
30149
Boiler11CyclesLow16
30150
Boiler12CyclesHigh16
30151
Boiler12CyclesLow16
30152
Boiler13CyclesHigh16
30153
Boiler13CyclesLow16
30154
Boiler14CyclesHigh16
30155
Boiler14CyclesLow16
30156
Boiler15CyclesHigh16
30157
Boiler15CyclesLow16
30158
Boiler16CyclesHigh16
30159
Boiler16CyclesLow16
30160
Boiler01Status4
16 bit unsigned
---
Boiler (1 – 16) status4 flags. These bits
indicate the state of various boiler statuses.
Boiler01 = Master or “Connected Boiler”
Boiler02 = Member01
…
Boiler16 = Member15
See the BoilerStatus4
Flags in Appendix A.
30161
Boiler02Status4
30162
Boiler03Status4
30163
Boiler04Status4
30164
Boiler05Status4
30165
Boiler06Status4
30166
Boiler07Status4
30167
Boiler08Status4
30168
Boiler09Status4
30169
Boiler10Status4
30170
Boiler11Status4
30171
Boiler12Status4
30172
Boiler13Status4
30173
Boiler14Status4
30174
Boiler15Status4
