RBI FUTERA XLF Series User Manual

MODBUS COMMUNICATIONS HeatNet Control V3
Page 107
Figure 64 MODBUS Input Variables (Read Only)
Address
Name
Raw Data
Type
Scale
Description
Valid Values/Range
30175
Boiler16Status4
30176
…
30207
RESERVED
---
---
---
---
30208
Boiler01DHWTemp
16 bit signed
---
Boiler (1 – 16) DHW temperature (if
available). See BoilerStatus4 to
32 – 250 °F
30209
Boiler02DHWTemp
30210
Boiler03DHWTemp
30211
Boiler04DHWTemp
30212
Boiler05DHWTemp
30213
Boiler06DHWTemp
30214
Boiler07DHWTemp
30215
Boiler08DHWTemp
30216
Boiler09DHWTemp
30217
Boiler10DHWTemp
30218
Boiler11DHWTemp
30219
Boiler12DHWTemp
30220
Boiler13DHWTemp
30221
Boiler14DHWTemp
30222
Boiler15DHWTemp
30223
Boiler16DHWTemp
30224
Boiler01Modulation
16 bit signed
---
The running (“display”) modulation. This is
typically the actual running modulation
except under special circumstances when
the boiler is running in a self-protection mode
(Op. Limit, ½ Fire Rate, etc.)
Boiler01 = Master or “Connected Boiler”
Boiler02 = Member01
…
Boiler16 = Member15
0 - 100
30225
Boiler02Modulation
30226
Boiler03Modulation
30227
Boiler04Modulation
30228
Boiler05Modulation
30229
Boiler06Modulation
30230
Boiler07Modulation
30231
Boiler08Modulation
30232
Boiler09Modulation
30233
Boiler10Modulation
30234
Boiler11Modulation
30235
Boiler12Modulation
30236
Boiler13Modulation
30237
Boiler14Modulation
30238
Boiler15Modulation
30239
Boiler16Modulation
30240
OperatingSetpoint
16 bit signed
---
This is the current operating or active
setpoint. It may be:
1) The normal heating setpoint.
2) The DHW setpoint if running in DHW
mode.
3) A calculated setpoint if running in Outdoor
Air Reset Mode
40 - 220 °F
