RBI HEATNET 3.0 Torus Series User Manual

CONTROL METHODS HeatNet Control V3
Page 45
DHW Method 4a Quick Start Settings
DHW METHOD 4a: Space Heating with DHW Override of Setpoint on Master Using an Aquastat
Master
Settings
Master Type
HeatNet Address
Combustion Air Damper
Automatic
Automatic
Off
Inputs
Local/Remote
OR OVR
Header Sensor
System Return
JPS1 Jumper must be cut to
service DHW
Local
Tank Aquastat
Yes
Optional
Outputs
System Pump On
Local Pump On
DHW Pump On
When Boiler Enabled
When Boiler Running
DHW Call
Member 2
Settings
HeatNet Address
Combustion Air Damper
2
Off
Inputs
Local/Remote
JPS1 Jumper must be cut to service DHW
Remote
Outputs
Local Pump On
When Boiler Running
Member 3
Settings
HeatNet Address
Combustion Air Damper
3
Off
Inputs
Local/Remote
JPS1 Jumper must be cut to service DHW
Remote
Outputs
Local Pump On
When Boiler Running
