RCA Audio/Video Receiver

46
SPECIFICATIONS
Amplifier Section
Continuous average power output of 100 watts* per
channel, min., at 8 ohms, from 20 Hz to 20,000 Hz with
no more than 0.2 %** total harmonic distortion (front).
* Measured pursuant to the Federal Trade Commission’s
Trade Regulation rule on Power Output Claims for Amplifiers.
** Measured by Audio Spectrum Analyzer.
Continuous Power Output
Front........................ 100 W per channel (1kHz, 0.8 %, 8 Ω)
Center .......................................... 100 W (1kHz, 0.8 %, 8 Ω)
Surround ................. 100 W per channel (1kHz, 0.8 %, 8 Ω)
Input (Sensitivity/Impedance)
CD, AUX, VCR/DVR, CD-R/TAPE/MD, DVD/LD, TV/SAT
............................................................... 200 mV/47 kΩ
Frequency Response
CD, AUX, VCR/DVR, CD-R/TAPE/MD, DVD/LD, TV/SAT
..................................................... 5 Hz to 100,000 dB
Output (Level/Impedance)
VCR/DVR REC, CD-R/TAPE/MD REC
200 mV/2.2 kΩ
Tone Control
BASS ...................................................... ± 6 dB (100 Hz)
TREBLE ................................................. ± 6 dB (10 kHz)
LOUDNESS ................... + 9 dB/+ 9 dB (100 Hz/10 kHz)
Signal-to-Noise Ratio (IHF, short circuited, A network)
CD, AUX, VCR/DVR, CD-R/TAPE/MD, DVD/LD, TV/SAT
.............................................................................. 96 dB
Signal-to Noise Ratio [EIA, at 1 W (1 kHz)]
CD, AUX, VCR/DVR, CD-R/TAPE/MD, DVD/LD, TV/SAT
.............................................................................. 79 dB
Video Section
Input (Sensitivity/Impedance)
VCR/DVR, DVD/LD, TV/SAT ....................... 1 Vp-p/75 Ω
Output (Level/Impedance)
VCR/DVR .................................................... 1 Vp-p/75 Ω
Frequency Response
VCR/DVR, DVD/LD, TV/SAT → MONITOR
....................................................... 5 Hz to 7 MHz dB
Signal-to-Noise Ratio .................................................... 55 dB
Cross Talk ..................................................................... 55 dB
FM Tuner Section
Frequency Range ................................ 87.5 MHz to 108 MHz
Usable Sensitivity
................................ Mono:13.2 dBf, IHF (1.3 µV/75 Ω)
50 dB Quieting Sensitivity .............................. Mono: 20.2 dB
Stereo: 38.6 dBf
Signal-to-Noise Ratio ....................... Mono: 73 dB (at 85 dBf)
Stereo: 70 dB (at 85 dBf)
Distortion ............................................ Stereo: 0.5 % (1 kHz)
Alternate Channel Selectivity ....................... 60 dB (400 kHz)
Stereo Separation ............................................. 40 dB (1 kHz)
Frequency Response ....................... 30 Hz to 15 kHz (±1) dB
Antenna Input ............................................ 75 Ω unbalanced
AM Tuner Section
Frequency Range ................................ 530 kHz to 1,700 kHz
Sensitivity (IHF, Loop antenna) .............................. 350 µV/m
Selectivity ..................................................................... 25 dB
Signal-to-Noise Ratio .................................................... 50 dB
Antenna ............................................................Loop antenna
Miscellaneous
Power Requirements .................................... AC 120 V, 60 Hz
Power Consumption ................................................... 250 W
In Standby ...................................................................... 1 W
Dimensions ........ 16-9/16 (W) x 6-4/16 (H) x 15-6/16 (D) in.
(420 (W) x 158 (H) x 391 (D) mm)
Weight (without package) ........................ 18 lb 8 oz (8.4 kg)
Furnished Parts
FM Antenna ......................................................................... 1
AM Loop Antenna................................................................ 1
Remote Control Unit ............................................................ 1
Operating Instructions ......................................................... 1
NOTE:
Specifications are typical, individual units might vary. Specifications
are subject to change and improvement without notice.
+0
–3
+0
–3
