Professional Two-Way Radio Instruction Manual
16
Removing the Battery
1. First, turn off the radio. Hold the top of
radio and press the belt clip to raise the
bottom of the belt clip. Lift the battery latch
in the direction of the arrow. See Figure 3.
2. When the bottom of the battery is raised,
release the battery latch and remove the
battery. (Note: When the battery is raised,
keep the angle between the battery and
main unit small so the battery doesn’t get
scratched.) See Figure 4.
Figure 3
Figure 4
