RCA RPJ129

12
2. Press the button to turn off power of your projector before connection.
3. Aer connect, press the buon to turn on unit and power indicator will light GREEN
4. Press the / SOURCE buon to select VGA mode and the video of VGA device will
show on projector screen.
5. Press the button to turn off unit power.
Please refer to the following table to adjust the output signal from computer
Type Resolution Frequency Field Frequency
PC
VGA 640x480
31.5 60
34.7 70
37.9 72
37.5 75
SVGA 800x600
31.4 50
35.1 56
37.9 60
46.6 70
48.1 72
46.9 75
XGA 1024x768
40.3 50
48.4 60
56.5 70
NOTE: In order to get the sound from the unit, please connect AV in cable when
you connect VGA input.
1. Turn off the unit before connect VGA cable.
Connect VGA Show The Image On Projector Screen
Follow below picture to connect VGA cable and device.
DC IN
KEYST ONE
USB 1
USB 2
HDMI 1
HDMI 2
VGA
VIDE O
To VGA PORT
NOTE BOOK
DECK TOP
OR
COMPUTER CABLECOMPUTER CABLE
