3
Getting Started
Conne
c
ting to Audio-Visual
Components
This receiver allows you to c onnect to a large variety
of audio or video components.
Before you Conne
c
t
• Protect components from po wer surges.
• Connect all components before plugging any
power cords into the wall outlet.
• Always turn off the receiver and/or components
before you connect or disconnect any cables.
• Contact consumer relations if you have questions
concerning the connections or components.
Note: Always make sure that color-coded pins match
the color of the terminals in w hich they are inserted.
The connection cable plugs and jacks are color-coded
as follows:
Speaker Terminals: RT 2500 - Red/Black (M ain
Speakers), Blue/Black (Center Speaker), Grey/Black
(Rear Speakers) and Brow n/Black (sub w oofer).
RT2500R - Red/ Black (Main, Center & Rear Speakers)
RCA Type Terminals: Red for the right (R) channel.
White for the left (L) channel. Yello w for the video.
Black for the po wered subwoofer.
Positioning the Cables
Cables should be pos itioned correctly to avoid audio
hum or interference. Below are a fe w suggestions:
• Insert all cable plugs into their jacks firmly.
• Place audio/video c ables to the sides of the receiv-
er’s back panel instead of straight do w n the middle
after you have connected the c omponents.
• Try not to coil any pow er c ables and keep them
aw ay from the audio/ video cables as much as possible.
• M ake sure all antennas and cables are properly
grounded.
Prote
c
t your Components from Overheating
• Do not block ventilation holes in any component.
Arrange the c omponents so that air can circulate
freely.
• Do not stack components directly on top of each
other.
• Allow adequate ventilation when placing your
components in a stand.
• Place an amplifier near the top shelf of the stand so
heating air rising from it will not affect other compo-
nents. If you have a satellite receiver, you should place
it on the top shelf.
EN
