RCF HC1600 - Technical Data

19
ENGLISH
TECHNICAL DATA
HC 1600 HC 2000
Output power
Stereo 2 Ω - 2 x 800 W RMS 2 Ω - 2 x 1000 W RMS
4 Ω - 2 x 650 W RMS 4 Ω - 2 x 800 W RMS
8 Ω - 2 x 350 W RMS 8 Ω - 2 x 500 W RMS
Bridge 4 Ω - 1600 W RMS 4 Ω - 2000 W RMS
8 Ω - 1300 W RMS 8 Ω - 1600 W RMS
Mono, 1 channel only 2 Ω - 900 W RMS 2 Ω - 1200 W RMS
4 Ω - 750 W RMS 4 Ω - 1050 W RMS
8 Ω - 380 W RMS 8 Ω - 650 W RMS
Frequency response 20 Hz ÷ 20 kHz (-0,2 dB) 20 Hz ÷ 20 kHz (-0,2 dB)
10 Hz ÷ 65 kHz (-3dB) 10 Hz ÷ 65 kHz (-3dB)
Distortion (THD+N) < 0.02% @ 1 kHz < 0.02% @ 1 kHz
< 0.1% @ 20 kHz < 0.1% @ 20 kHz
Intermodulation < 0.03% @ max. pot. (4 Ω) < 0.03% @ max. pot. (4 Ω)
Damping factor > 200:1 (8 Ω) > 200:1 (8 Ω)
Slew rate 50 V / µS 50 V / µS
Signal / noise rate > 103 dB ”A” weighted > 102 dB ”A” weighted
Crosstalk > 70 dB @ 1 kHz > 70 dB @ 1 kHz
Input sensitivity 0 dBm (0.775 V RMS) 0 dBm (0.775 V RMS)
+4 dBm (1.23 V RMS) +4 dBm (1.23 V RMS)
Input impedance 20 kΩ balanced 20 kΩ balanced
10 kΩ unbalanced 10 kΩ unbalanced
Protection devices Temperature, DC, RFI Temperature, DC, RFI
short circuit, Soft-Start, short circuit, Soft-Start,
Thermal on transformer thermal on transformer
Input connectors XLR, 1/4” stereo (TRS) jack XLR, 1/4” stereo (TRS) jack
(per channel)
Output connectors 4 way SPEAKON 4 way SPEAKON
(per channel)
Cooling 2 variable speed fans 2 variable speed fans
Power supply voltage 230V ~ 50 Hz (7.5 A) 230V ~ 50 Hz (10 A)
(max. current) 115V ~ 60 Hz (15 A) 115V ~ 60 Hz (20 A)
Dimensions 88 x 482 x 455 mm 88 x 482 x 455 mm
Rack units 2U 2U
Net weight 17 kg 18 kg
