10
ENGLISH
SPECIFICATIONS
TYPE
LOUDSPEAKERS
CROSSOVER FREQUENCY
COVERAGE ANGLE
SENSITIVITY
MAX. SOUND PRESSURE
INPUT VOLTAGE
POWER
FREQUENCY RESPONSE
CABINET
DIMENSIONS (W, H, D)
REQUIRED WALL / CEILING
THICKNESS FOR THE INSTALLATION
NET WEIGHT
COLOUR
ACCESSORIES
2 way bass-reflex (vented) for flush-mounting
5” woofer, 0.75” dome tweeter
3 kHz
120° horizontal, 100° vertical
90 dB (1 W, 1 m)
108 dB (60 W)
100 – 70 V
- 30-20-10-5 W (100 V)
- 15-10-5-2.5 W (70 V)
- max. 60 W (16 Ω)
180 Hz ÷ 20 kHz
high density polystyrene
195 mm, 270 mm
Depth:
- with BTicino® 16102 box 72 mm
- with rear metallic cover 90 mm
min. 10 mm; max. 26 mm
3 kg
white (MQ 50i – W)
rear metallic cover
