4
ENGLISH
DESCRIPTION
RCF S.P.A. WOULD LIKE TO THANK YOU FOR HAVING PURCHASED THIS
PRODUCT, WHICH HAS BEEN DESIGNED TO GUARANTEE RELIABILITY
AND HIGH PERFORMANCE.
MQ 50i is a 2 way compact loudspeaker for indoor wall flush-mounting
installation.
Its “bass-reflex” (/ vented) cabinet includes a 5” woofer and a waveguide-
loaded dome tweeter (to ensure a sound correct dispersion over a wide
coverage angle).
It includes a transformer inside for the connection to (100 – 70 V) constant
voltage lines, yet it can also be set to 16 Ω (low impedance connection).
The power / mode selection is made by means of the front panel rotary switch.
Its power is:
a. 30-20-10-5 W (selectable) on 100 V constant voltage line.
b. 15-10-5-2.5 W (selectable) on 70 V constant voltage line.
c. Max. 60 W on low impedance (16 Ω).
Its cabinet is made of high density polystyrene with a painted steel protection
grille.
It can be mounted on a flush-mounting box type “Multibox” (2 modules) by
BTicino® (or equivalent).
It has a rear metallic cover with a cable guide (for installation on plasterboard
or other types of panels).
MQ 50i is available in white only (MQ 50i-W).
WARNING: loudspeaker connections should be only made by qualified and
experienced personnel having the technical know-how or sufficient specific
instructions (to ensure that connections are made correctly) in order to prevent
any electrical danger.
To prevent any risk of electric shock, do not connect loudspeakers when the
amplifier is switched on. Before turning the system on, check all connections
and make sure there are no accidental short circuits. The entire sound system
shall be designed and installed in compliance with the current local laws and
regulations regarding electrical systems.
CONNECTION AND PRESETTING
