20
EN
5. Now place the Vertical Fly Bar on top of a Q15 speaker and screw it with the 4 screws provided.
The protruding part of the 10° bracket of the lower speaker must be inserted on the respective seat on the upper speaker. Then depending on
which angle is chosen, screw in the last two screws.
NOTE: The exact same operations must be done on both sides of the speaker
NOTE: The exact same operations must be done on both sides of the speaker
6. VERTICAL HANGING WITH A 10° ANGLE
