RCS TBZ48A - Changeover Valve and Z-Wave Intro; Changeover Valve Type Configuration; Z-Wave Network Installation Overview

DCN: 140-02121-02 Page 7
Changeover Type (CO) Range: C or H Default: C
Sets the Changeover type, Changeover with Cool (C) or Changeover with Heat (H)
Only for Heat Pump systems, Changeover valve (or reversing valve) changes the system
from heating to cooling operation.
Z-Wave Installation
See the Operating Guide for instructions on installing the thermostat on a Z-Wave network.
System Settings Summary
Setting
Range
Default
Sys Type
Std or HP
Std
Fan Type
Gas or Elec
Gas
C/O Type
w/Heat or w/Cool
w/Cool
2
nd
Stage Heat
Y or N
N
Aux Heat
Y or N
Y
2
nd
Stage Cool
Y or N
N
H/C Delta
3 – 15 deg
3
Heat Delta Stage 1 On
1 – 6
1
Heat Delta Stage 1 Off
0 – 5
0
Heat Delta Stage 2 On
2 – 7
2
Heat Delta Stage 2 Off
0 – 6
0
Heat Delta Stage 3 On
3 – 8
3
Heat Delta Stage 3 Off
0 – 7
0
Cool Delta Stage 1 On
1 – 6
1
Cool Delta Stage 1 Off
0 – 5
0
Cool Delta Stage 2 On
2 – 7
2
Cool Delta Stage 2 Off
0 – 6
0
Max Heat SP
55-96F (4-42C)
90F
Min Cool SP
60-99F (6-45C)
60F
Min Run Time
1-9 min
3
Min Off Time
1-9 min
5
F/C Mode
F or C
F
Sensor Calibration
Internal -7 to +7
0
Backlight Timeout
10-30
20
Restore Defaults
Yes or No
No
Exit = no
Display Lock
Y or N
N
Locks out front buttons
Test Mode
Y or N
N
Reduces delays for testing
Heat Purge
0-90 seconds
0
Cool Purge
0-90 seconds
0
