Main Menu > Schedules
Schedules
The Schedules Screen allows you to review and set the setback schedule for the thermostat. The TS40
has 4 x 7 schedule. Four times a day can be selected for Heating and Cooling setpoints. Each day of the
week can have a different schedule. Groups of days can be copied with the same schedule. When the
TS40 is set to “Run” mode, the schedule will be executed daily, with the setpoints being changed as per
that days schedule stored in the thermostat. “Hold” mode stops schedule operation and holds the current
setpoints until changed manually or by network commands.
The schedules Screen gives you the option of setting an custom setback schedule or to load one of two
preset schedules.
Menu Options
• Heat and Cool: You can change the individual day/hour and setpoints for the Heat and Cool
schedule by selecting this menu item.
• Preset: Comfort: This is a preset schedule with mild setbacks. Select this menu item to load the
Comfort schedule into the thermostat.
• Preset: EnergyMiser: This is a preset schedule with deeper setbacks. Select this menu item to
load the EnergyMiser schedule into the thermostat.
Schedules Screen
Select Schedule
Heat and Cool
Preset: Comfort
Preset: EnergyMiser
Done
Select
Done
Select
Return to Main Menu Screen
Select the schedule to view or modify
To Next Page
