REACH MRS100

User Manual

with server and encoder. If there is router between the PC and server or

encoder, or they are at deferent VLAN, server and encoder can not be

detected. You can also get IP address via LCD display at the front panel of

the equipments.

3.2 IP configuration of server

After you got IP address of DSS-R server via DSSIpViewer, you can

change IP address of the server through IE browser.

Connect your PC to LAN or WAN interface of the server with a LAN

cable.

Configure your PC’s IP address to the same segment with DSS-R

server

Enter the IP address of server at the address field of IE browser and

press “Enter”.

Use the user name of “admin” and password of “admin” to log in the

system

Go to Senior Management

System Set

IP Address Modification

to set the IP address, sub mask and gateway of the server. Click save

button and then the server will reset automatically.

3.3 Initial configuration of DSS-ENC 110

The default IP address of ENC 110 from factory is random and you can

see the IP address on the LCD of font panel (assume IP is 192.168.3.93

sub mask 255.255.255.0 and gateway 192.168.3.1. Set your PC’s IP

address to 192.168.3.110, sub mask 255.255.255.0). You can go to the

webpage of the encoder to set the IP address you need. For explanation

convenient, assume the IP you want to set as 192.168.1.101, sub mask

255.255.255.0 and gateway 192.168.1.1.

Check connection. Go to your PC Start ->Run->cmd, input Ping

192.168.3.92. If you get the replays, means the connection is ok. If not,

please check the cable connection and PC’s IP.
