Realtek RTL8201(L) - Register 21 PHY 1_2; Register 22 PHY 2; Register 23 Twister_1; Register 24 Twister_2

RTL8201(L)
2002-01-18 Rev.1.04
16
6.13 Register 21 PHY 1_2
Address Name Description/Usage Default/Attribute
21:<15:0> PHY1_2 PHY 1 register (functions as RTL8139C<78>) R/W
6.13 Register 22 PHY 2
Address Name Description/Usage Default/Attribute
22<15:8> PHY2_76 PHY2 register for cable length test (functions as RTL8139C<76>) RO
22:<7:0> PHY2_80 PHY2 register for PLL select (functions as RTL8139C<80>) R/W
6.14 Register 23 Twister_1
Address Name Description/Usage Default/Attribute
23:<15:0> TW_1 Twister register (functions as RTL8139C<7c>) R/W
6.15 Register 24 Twister_2
Address Name Description/Usage Default/Attribute
24:<15:0> TW_2 Twister register (functions as RTL8139C<7c>) R/W
