RTL8201(L)
2002-01-18 Rev.1.04
2
1. Features
The Realtek RTL8201(L) is a Fast Ethernet Phyceiver with MII interface to the MAC chip. It provides the following
features:
Supports MII interface
Supports 10/100Mbps operation
Supports half/full duplex operation
IEEE 802.3/802.3u compliant
Supports IEEE 802.3u clause 28 auto negotiation
Supports power down mode
Supports operation under Link Down Power
Saving mode
Supports repeater mode
Speed/duplex/auto negotiation adjustable
3.3V operation with 5V signal tolerance
Low operation power consumption
Adaptive Equalization
25MHz crystal/oscillator as clock source
Multiple network status LED support
Supports 7-wire SNI (Serial Network Interface)
interface
Flow control ability support to co-work with
MAC (by MDC/MDIO)
48-pin LQFP package
2. General Description
The RTL8201(L) is a single-port Phyceiver with an MII (Media Independent Interface). It implements all 10/100M Ethernet
Physical-layer functions including the Physical Coding Sublayer (PCS), Physical Medium Attachment (PMA), Twisted Pair
Physical Medium Dependent Sublayer (TP-PMD), 10Base-Tx Encoder/Decoder and Twisted Pair Media Access Unit
(TPMAU). It is fabricated with an advanced CMOS process to meet low voltage and low power requirements.
The RTL8201(L) can be used as a Network Interface Adapter, MAU, CNR, ACR, Ethernet Hub, Ethernet Switch.
Additionally, it can be used in any embedded system with an Ethernet MAC that needs a twisted pair physical connection.
