reci FCA Series - Rear Panel

Beijing Reci Laser Technology Co., Ltd
User Guide for FCA Series Hand Laser Welding System
18
7: Touch screen - Detailed fault view interface
8: Touch screen - Auxiliary parameters setting
interface
9: Touch screen - Signal detection interface
10: Touch screen - Decryption settings interface
4.2
Rear Panel
The layout of the rear panel is shown in Figure 4.2.
Figure 4.2 The Rear Panel of the FCA series fiber laser
The specific interface functions of the rear panel are shown in the table 4.2.
