User Guide for FCA Series Hand Laser Welding System
28
NO
MODULE
DESCRIPTION
FUNTION
port.
2.
Laser output
parameter
Group
Save and select the process parameters, only two digits can
be input.
Peak power
Set the peak power of the laser.
Wobble Freq
Wobble frequency of the galvanometer, the input range is
0~300Hz.
Wobble Amp
Wobble amplitude of the galvanometer, the input range is
0~5.0mm.
F
The modulation frequency of the laser, the input range is
20~20000Hz. Default 100Hz.
D
The duty cycle of the laser, the input range is 0~100%.
Default 100%.
3.
Spot welding
parameters
Duration time
The duration time of the laser, the input range is
1~60000ms. Default 200ms.
Interval time
The interval time of the laser, the input range is
1~60000ms. Default 200ms.
4.
Galvanometer
parameter
correction
Left/ Right
Used to realize the setting of the center movement
direction of the galvanometer.
Center offset
Used to realize the setting of the movement value of the
center of the galvanometer, the input range is 0~2.50mm.
Amplitude
correction ratio
Used to realize the correction of the amplitude of the
galvanometer, the input range is 0~4.00.
5.
Eliminate
fatal failures
Eliminate fatal
Eliminate fatal failures of the current device
6.
System
language
settings
“
设为汉语
”
With this button, you can translate the system language to
Chinese.
7.
Auxiliary
parameter
setting
Gas on delay
Ventilation time before turning on the laser, the input range
is 0~3000ms. Default 200ms.
Gas off delay
Ventilation time after turning off the laser, the input range
is 0~3000ms. Default 200ms.
Power on percent
The power percentage when the laser is turned on, the
input range is 0~100%. Default3 0%.
Power on time
The rise time from the percentage of turn-on power to the
setting peak power, the input range is 0~2000ms. Default
500ms.
Power off
percent
The power percentage when the laser is turned off, the
input range is 0~100%. Default 80%.
Power off time
The fall time from the setting peak power to the percentage
of the laser power off, the input range is 0~2000ms.
Default 500ms.
Wire delay
Compensation time for wire feeding, the input range is
0~2000ms. Default 0ms.
