Operating instructions DFA 127 Full Power Rev. B 11/2006 Page 13 of 20
Configurations
Configurations of the DFA 127 can only be made with the electronic BDE-D. If a
toggle switch is connected, a BDE-D must be connected briefly for the configura-
tion.
Further information for parameter changes can be taken from the user manual of
the BDE-D (no. 903 109 271).
Please always leave the configuration review sheet in the drive!
6.2 Parameter description
Parameter Setting
range
Factory
default
Description
DRIVING CYCLE
Closing speed 0 - 40
(5 ā 20 s)
18 Slider control with 40 steps
Opening speed 0 - 40
(3 - 20 s)
36 Slider control with 40 steps
TIME DELAY
OPEN
Time delay open 0 - 40
(0 - 60 s)
2 Effective with AKA, AKI and push to
actuate
0 - 20: Steps of 1 s
21 - 40: Steps of 2 s
Time delay SSK 0 ā 40
(0 - 60 s)
4 Effective with SSK
0 - 20: Steps of 1 s
21 - 40: Steps of 2 s
DRIVE
Opening angle 0 - 40 35 The opening angle is estimated dur-
ing the calibration run and is equiva-
lent to the value of 40.
6.3 Different factory defaults for door types Low Energy
Parameter Factory
default
Parameter Factory
default
DRIVING CYCLE
Closing speed 10 Opening speed 20
