Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 32/ 56
→ VRR manually Signal for connecting a rod lock (manual locking).
0V/open = rod lock closed
24V = rod lock open
▪ If the lock is closed (0V/open) the door can be moved
freely in a similar way to manual mode. The text display of
the BDE-D changes alternately between the current oper-
ating mode and
Manually locked
. The operating mode can
be changed at will with the BDE-D.
▪ If
the lock is opened (24V) the control unit goes back to the
active state after only approx. 4 seconds. It is assumed
that this is enough time to remove the key from the lock
cylinder, before the door is opened by a triggered motion
→ Reset SÖK_NSK Restart inhibitor after activation and reset of a SÖK/NSK.
The SÖK/NSK with restart inhibitor function is activated by
configuring the Reset SÖK/NSK signal on AUX0_IN or
AUX1_IN,
After resetting on SÖK or NSK signal, the control remains in
the corresponding operating mode and status 116 restart in-
hibit is displayed until the new reset signal is activated or the
control is restarted (reset).
→ SIA Safety signal of presence detector.
0V/open = active safety
24V = passive safety
▪ The signal prevents a closed door from being opened and
an open door from being closed.
▪ In all other phases the signal is disabled.
▪ If the sensor test is configured, the sensor is tested before
each opening and closing.
→ AUX0_OUT Configurable output signal on STM.
▪ Terminals 8, 9, 10 on STM, floating change over contact
→ Disabled X
→ Test sensors This output must be connected to the test input of class 2 safe-
ty sensors. Before every potentially dangerous door move-
ment, the output is briefly activated to check if the sensor is
functioning correctly, incl. signal path. When the door is sta-
tionary the test is repeated every hour.
▪ If this output is configured all the connected safety sensors
(SIS and SIO) must have a test input and the test signal
must be connected in parallel to all sensors.
