Parameter explanations V2.1_V2.6
2
IRA_B8_EN_2V2_REC_102-020401137 6/ 56
Parameter explanations V2.1_V2.6
PARAMETER W COMMENT
DRIVING CYCLE
→ Opening speed 36 Driving speed of the opening door.
0 = lowest speed
40 = highest speed
▪ The maximum reachable speed depends on the driven
distance (door width) and the acceleration setting.
▪
DIN: >1.5 s <4 s
→ Open
→ Acceleration 30 Start-up acceleration while opening.
0 = no acceleration
40 = heavy acceleration
→ Declaration 30 Braking moment while opening
0 = small braking force
40 = large braking force
→ Creep section 0 Final creep section while opening.
0 = no creep section
1 = creep on the last 2.5% of travel way
40 = 100% creep on 100% of travel way
▪ The creep section is calculated on the basis of the maxi-
mum opening distance driven. Consequently, the creep
drive is only carried out at the correct position after the first
complete door movement has
taken place.
→ Close
→ Acceleration 30 Start-up acceleration while closing.
0 = no acceleration
40 = heavy acceleration
→ Deceleration 30 Braking moment while closing.
0 = small braking force
40 = large braking force
