 Internal cooling system maintains appropriate operating temperature.
REAR SSD MODULE
The REAR SSD MODULE secures onto the back of the DSMC brain to serve as a rear location for recording
onto 1.8” REDMAG SSD media.
QUAD BATTERY MODULE
 The QUAD BATTERY MODULE holds up to four REDVOLTs or two REDVOLT-XLs.
PRO I/O MODULE
REAR SSD MODULE
