-24-
Drawing No. LP0932 Released 2018-01-12

-125 to 125
3-LC




 
SETPOINT OUTPUT 1
POWER

CURRENT
TRANSFORMER
OUTPUT 2
POWER
CONTROLLER
STATUS

PID
GROUPRAMP RATE
SETPOINT

PROFILE
STATUS

PROFILE
TIME


 

STARTING
PROFILE
STARTING
PROFILE
SEGMENT

PROFILE
INDICATOR
OUTPUT
POWER
OFFSET
PROPORTIONAL
BAND

INTEGRAL
TIME



 
DERIVATIVE
TIME
ALARM 2
VALUE
SETPOINT
SELECT
ALARM
RESETVALUE
ALARM 3


 
AUTO-TUNE
START
CONTROL
MODE
DEVIATION
VALUE

CONTROL
MODE
TRANSFER
ACCESS
CODE
P
P
Programming/model dependent.

INTEGRATION
DEFAULT

ALARM 1
VALUE

SETPOINT
CONTROL
MODE

SETPOINT
2

SETPOINT
1

SELECTION DESCRIPTION
dIP
Display: accessible in Display Loop.
PArA
Parameter: accessible in Parameter Loop
Id
Hide: accessible in Hidden Loop.
LOC
Locked: not accessible in loops.
dPr
Display/read: read only in Display Loop, but read/write
in Hidden Loop.
The following parameters can be configured for the selections
described above. See Programming Loops section for a description of
loops and parameters.
PARAMETER SELECTION
FACTORY
SETTING
P dIP, PArA, Id, LOC, dPr dIP
C1 dIP, PArA, Id, LOC dIP
OP1 dIP, PArA, Id, LOC, dPr PArA
OP2 dIP, PArA, Id, LOC, dPr PArA
PrP dIP, PArA, Id, LOC, dPr PArA
PId dIP, PArA, Id, LOC, dPr PArA
r- dIP, PArA, Id, LOC, dPr dIP
P dIP, PArA, Id, LOC, dPr PArA
r-i dIP, PArA, Id, LOC, dPr PArA
ProF PArA, Id, LOC PArA
Pg PArA, Id, LOC LOC
Pind ♦ dIP, LOC dIP
OPOF PArA, Id, LOC PArA
ProP PArA, Id, LOC PArA
In PArA, Id, LOC PArA
dR PArA, Id, LOC PArA
dIn PArA, Id, LOC LOC
AL-1 PArA, Id, LOC PArA
AL-2 PArA, Id, LOC PArA
AL-3 PArA, Id, LOC PArA
ALr PArA, Id, LOC PArA
PL PArA, Id, LOC PArA
N Id, LOC Id
CrL Id, LOC Id
P Id, LOC LOC
rnF Id, LOC Id
0
Full access to Display, Hidden, and
Configuration Loops
-1 to -125
Code necessary to access
Configuration Loop only. *
1 to 125
Code necessary to access Hidden
and Configuration Loops. *
* If PLOC is active, Configuration Loop is not accessible.
0
Cod
Shaded parameters are programming/model dependent.
PARAMETER SELECTION
FACTORY
SETTING
dV dIP, LOC dIP
P1 dIP, PArA, Id, LOC dIP
P2 dIP, PArA, Id, LOC LOC
Parameters may not appear in selected loop if not applicable to
current operating mode.
Ex. 1. If A2 = NON, AL-2 will not be displayed in selected loop.
2. If CrL = ONOF, PID parameters will not be displayed in selected loop.
♦ Programming Pind for diP will enable the Prole Indicator segment, which
is located in the lower left of the unit display. When enabled the Prole
Indicator segment will ash to indicate that a prole is currently running.
