PRODUCT DESCRIPTION
Models
3
PRODUCT DESCRIPTION
This submersible pump is for use in basins or lift stations and is suitable for pumping clear water and other
non-explosive, non-corrosive liquids. Products with tethered float switches (RL-SS50T and RL-SS100T) are
suitable for effluent removal applications where semi-solids are no greater than 3/4" (19 mm) in diameter.
Do not use the pump in applications where sewage or any other debris (gravel, sand, floating debris, etc.),
abrasives, or corrosives are present.
The pump motor is equipped with an automatic resetting thermal protector, and may restart unexpectedly.
Thermal Protector tripping is an indication of motor overloading or overheating, which can be caused by
application issues such as an obstructed pump impeller, float stuck in the ON position, pump running dry,
pump air-locked, pump short cycling, excessively high or low voltage supply, or possibly a pump, motor,
bearings, or seal that have reached the end of their useful life.
Please examine your pump carefully to ensure that no damage occurred during shipment. If damage has
occurred, please contact the place of purchase. They will assist you in replacement or repair if required.
This product is covered by a Limited Warranty for a period of 5 years from the date of original purchase by
the consumer. For complete warranty information, refer to www.redlionproducts.com
; or call Technical Sup-
port for a printed copy.
Models
Flow Rates
Specifications
Model HP Amps Voltage Watts Float Type On/Off Levels Minimum Basin Diameter
RL-SS50V 1/2 5 115 520 Vertical 7.5” (191 mm)/4.5” (114 mm) 11” (279 mm)
RL-SS50T 1/2 5 115 520 Tethered 14.3” (363 mm)/6” (152 mm) 18” (457 mm)
RL-SS100T 1 8 115 925 Tethered 16.8” (427 mm)/8.4” (213 mm) 18” (457 mm)
Gallons/Liters per Hour
At Height:
(Head)
5 ft (1.5 m) 10 ft (3 m) 15 ft (4.6 m) 20 ft (6 m) 25 ft (7.6 m) 30 ft (9.1 m) Shut Off
RL-SS50V 3000 / 11,356 2400 / 9085 1800 / 6814 1100 / 4164 - - 25 ft (7.6 m)
RL-SS50T 3000 / 11,356 2400 / 9085 1800 / 6814 1100 / 4164 - - 25 ft (7.6 m)
RL-SS100T 4800 / 18,170 4300 / 16,277 3700 / 14,006 3000 / 11,356 2200 / 8328 1300 / 4921 35 ft (10.7 m)
Discharge Size
RL-SS50: 1-1/2" FNPT RL-SS100T: 2" FNPT (1-1/2" FNPT adapter included)
Pump Housing Stainless Steel and Cast Iron (including volute and screen)
Impeller Cast Iron, vortex clog-resistant design - capable of passing ¾” diameter semi-solids
Motor Single phase PSC with automatic reset thermal overload protection
Hardware 300 series stainless steel
Bearings Ball bearings
Pump Shaft Seal Mechanical, spring-loaded, stationary carbon with Nitrile boot and rotating ceramic seat
Cooling
The motor housing contains oil to cool the motor and to lubricate the bearings and seals. These pumps can
be operated with the motor housing partially exposed for extended periods of time. However, for the best
cooling and longest motor life, the liquid level being pumped should normally be above the top of the pump
housing.
