5
1 INTRODUCTION
1.2 Specifications
R-12-350RS R-24-350RS
Output Voltage 200 / 220 / 230 / 240VAC ± 5%
Rated Power 350W
Max. Rated Input Current 44A 22A
Surge Power 700W
Waveform Pure Sine Wave (THD<3% @ VCD, linear load)
Frequency 50/60Hz ± 0.1%
Nominal Input Voltage 12VDC 24VDC
Input Voltage Range 10.0~15.5VDC 20.0~31.0VDC
Efficiency (at rated VDC full) 89% 90%
No Load Power Consumption
Power Saving mode <90mA <60mA
No load standby <0.9A <0.5A
Battery Low Shutdown 10V ± 0.25V 20V ± 0.5V
Battery Low Alarm 10.5V ± 0.25V 21V ± 0.5V
Battery Low Restart 12V ± 0.25V 24V ± 0.5V
Battery High Alarm 15V ± 0.25V 30V ± 0.5V
Battery High Shutdown 15.5V ± 0.25V 31V ± 0.5V
Battery High Restart 14.5V ± 0.25V 29V ± 0.5V
Protections Overload / Short Circuit / DC Over or Under Voltage / Over Temp.
Working Temperature -20°C~50°C (Derates to 60°C)
Storage Temperature -30°C~70°C
Working Humidity Max 90% RH non-condensing
Safety & EMC Certified EN 60950-1
Certified EN55022, EN 55024, EN 61204-3,
EN61000-3-2, -3-3, EN61000-6-1, -6-3,
IEC 61000-4-2, 3, 4, 5, 6, 8, 11
Dimensions 150x68x187 mm
Weight 1.6Kg
Cooling Load (53 ± 3%) and temperature (55 ± 5°C) control fan
Power Saving If set - Active after 25 seconds with load < 20W
