6
1 INTRODUCTION
1.4 Specifications
Electrical Specifications
Inputs
AC Input
Input Voltage Range (nominal) 100-130 Vca, 50 - 60Hz
Power Rating 560W
Efciency 80 - 90%
Connection IEC Mains Plug
DC Input
Input Voltage Range 9 - 30 Vcc
Turn ON/OFF Threshold 12V (24V) 13.2V/12.7V (26.4V/25.4V)
Power Rating 520W
Efciency 94%
Connection Phoenix 1967498 Connector
*1
Solar Input
*2
Input Voltage Range 9 - 30 Vcc
Turn ON (Open Circuit Voltage) 17.5V
Power Rating 520W
Efciency 93%
Connection Phoenix 1967498 Connector
*1
Output
Total Battery Capacity 40 - 800Ah
Output Battery Volts (Nominal) 12V
Output Battery Volts (Minimum) 4V
Maximum Current on Load Disconnect Wire 1A
Memory Save on Battery Disconnect Yes
Output Protection
Short Circuit Protection Yes
Surge Protection Yes
Reverse Polarity Protection Yes
Overload Protection Yes
Max Volts @ Battery Terminals (25°C/77°F Nominal) Storage Mode Touring Mode Float
Gel Setting 14.4V 14.4V 13.5V
AGM Setting 14.4V 14.4V 13.5V
Calcium Setting 16.0V 15.2V 13.5V
Standard Lead Acid Setting 15.5V 14.8V 13.5V
Lithium Setting 14.5V 14.5V 13.6V
Output Current (Nominal) 30A
Thermal Specifications
Operating Temperature -40°F to 176°F
SLA, AGM, or Calcium Charging Temperature -13°F - 140°F (
32°F - 140°F when Vop <10.5V)
GEL or LiFePO
4
Charging Temperature 32°F - 140°F
Over Temperature Shutdown Yes
Temperature Compensation
Standard Lead Acid, AGM, Gel or Calcium Battery +16.7mV / °F < 77°F < -16.7mV / °F
Lithium Setting 104°F < 0.28%/°F < 140°F
Compliance
EMC CAN ICES-1/NMB-1
Safety UL Listing (Canada, USA and Mexico)
Environmental RoHS Compliant
General Specifications
Main Unit Dimensions 17.5”x7.3”x3.1”
Remote Dimensions 7.3”x2.9”x1.1”
Kit Weight 12.1lbs
Warranty 2 years
*1 Torque between 1.7-1.8 Nm
*2 Any solar panel connected to the system must be UL listed .
