Reebok EDGE series Instalaltion Guide

216
Lower Handlebar Cover-Left 2
217 Lower Handlebar Cover-Right 2
218 M6X14 Screw 2
219 Ø 8.5 x20 Washer 2
220 Ø 8 Spring Washer 12
221 7 Pin Speed Sensor Wire 1
223 Handlebar end cap 2
224 Fixed Handlebar end cap 2
225 Hand Pulse Sensor-Upper 2
226 Hand Pulse Sensor-Lower 2
227 M4X15 Screw 39
228 Speed sensor Wire upper 1
229 M3X12 Screw 4
231 Handle pulse sensor wire 2
232
Handlebar bearing bushing upper OD20X14
2
233 Handlebar bushing Ø47.1x23 2
234
Handlebar bearing bushing –lower OD23X23
2
301 Side cover-outside 2
302 Crank disk 2
303 Upright lower cover 1
304 Main Chain Cover-Left 1
305 Main Chain Cover-Right 1
309 Plastic Insert 9X3mm 16
310 M4X12 Screw washer 8
312 Plastic Insert 10X2mm 2
403 Crank Arm Set 2
405 Driving Belt 1
406 Crank Shaft Plate 2
407 Driving Belt plastic pulley 1
408 Crank Shaft 1
410 M6X20 Screw 6
411 M5X30X30 Bolt 4
412 M8X20X20 Allen Head Screw 2

Reebok EDGE series Specifications

General

Display Type	LCD
Transport Wheels	Yes
Maximum User Weight	120 kg
Weight Capacity	120 kg
Display Metrics	Time, speed, distance, calories, pulse
Handlebar Adjustment	Yes
Seat Adjustment	Vertical and Horizontal
