Reebok EDGE series Instalaltion Guide

Spare Part List
Part No. Part name
Quantity
101 M8X65 Bolt 4
102 Ø 8X17X1.5 Washer 10
103 Rear Stabilizer 1
104 Bushing 1
105 Stabilizer Tube End Cap 4
106 Transportation Wheel set 2
107 Speed sensor 1
108
Rear Stabilizer Tube adjustment foot
2
109 Front Stabilizer Tube foot 2
110 6004Z Bearing 2
111 Front Stabilizer 1
114 M5X14 Screw 6
116 Main Frame 1
118 Lower section upright bushing 1
119 M8X15X15screw 8
120 Speed sensor Wire-Lower 1
122 M8x20x20 screw 4
201 Heart rate Handle Bar Foam Grip 2
203 Upright 1
204
Upright Axle Bushing 17.2x47.2x10mm
2
205 Action Handlebar Cover-Rear 2
206 Action Handlebar Cover-Front 2
207 Lower Handlebar bushing 4
209 Lower Handlebar Tube 2
210 M8X12 Screw 8
212 Ø 8 curve Washer 12
213 Action Handlebar-Upper-Left 1
214 Action Handlebar Foam Grip 2
215 Action Handlebar-Upper-Right 1

Reebok EDGE series Specifications

General

Display Type	LCD
Transport Wheels	Yes
Maximum User Weight	120 kg
Weight Capacity	120 kg
Display Metrics	Time, speed, distance, calories, pulse
Handlebar Adjustment	Yes
Seat Adjustment	Vertical and Horizontal
