M8 x 39mm Bolt (52)
M8 x 65mm Bolt (48)
M8 x 54mm Bolt (43)
M8 x 52mm Bolt (18)
M6 Washer (49)
M8 Washer (32)
M8 Nylon Locknut (17)
M10 Washer (50)
M10 Nylon Locknut (51)
M6 x 15mm Screw (41)
M6 x 38mm Screw (42)
M8 x 50mm Carriage Bolt (53)
M10 x 20mm Bolt (47)
M10 x 57mm Bolt (26)
M10 x 65mm Bolt (44)
M10 x 138mm Bolt (45)
PART IDENTIFICATION CHART
R
efer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual.
Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
