9
14. Attach the Curl Pad (22) to the Curl Post (11) with
two M6 x 15mm Screws (41).
16. Make sure that all parts are properly tightened before the weight bench is used. The use of all
remaining parts will be explained in ADJUSTMENTS starting on the next page.
15. Insert the Inner Barbell (60) into the Outer Barbell
(59) and align the holes. Using a hammer, tap the
two Roll Pins (58) into the holes until they are
flush with the Outer Barbell.
14
2
2
41
11
15
59
60
58
