Features
• mA sourcing, simulation and measurement
• 0-28 VDC measurement to check loop voltage
• 0.02% accuracy and 0.001% of span display
• Simulate mA and % of span display
• Selectable step or ramp outputs
• 24V loop power supply
Specifications
Power supply: 9V battery (ANSI/NEDA 1604A or IEC 6LR619V alkaline)
Battery life: About 20 hours under the condition of 10mA
Size: 200×100×40mm (with holster)
Weight: 550g (with holster)
Includes: Set of CF-36 industrial test leads (alligator clips
attached to probes), protective holster, carrying case,
and battery
Output Functions
Applicable range from 18 to 28°C, within one year of calibration.
Output Range Output Range Resolution Accuracy Note
Current 20mA 0.000 to 22.000mA 0.001mA
±0.05% of set
value ±4A
Max 1K at
20mA, see
Note 1
Simu.
transmitter
(absorp.
current)
-20mA
0.000 to
–22.000mA
0.001mA
Max 1K at
20mA, see
Note 2
Loop power 24V - - ±10%
Max output
current up to
25mA
