Input Functions
Applicable range from 18 to 28°C, within one year of calibration.
Input Range Input Range Resolution Accuracy Note
Voltage 28V -0.200 to 28.000V 1mV
±0.02% of
reading ±2mV
Input
resistance
2M
Current 20mA -1.000 to 22.000mA
0.001mA
±0.02% of
reading ±4A
Max 1K at
20mA, see
Note 2
Loop
power
20mA 0.000 to 22.000mA
Providing
24V loop
power
Note 1: When the battery voltage exceeds 6.8V, the max. load is 1K at
20mA. When its voltage lies between 5.8V and 6.8V, the max
load is 700 at 20mA.
Note 2: Power supply range: 5 to 25VDC.
Note 3: Temperature coefcient: ±0.005% of the range per °C for the
temperature ranges 5°C to 18°C and 28°C to 40°C.
