Instrument Description
1. LCD screen
2. Power button
3. Single step/auto switch button
4. 25% single step setting/auto ramp button
5. 0% & 100% of setting/auto ramp start button
6. Output/input on-off button
7. Unit mA%/V select button
8. output digit selection button
9. output value setting button
10. Input/output terminals
7
8
9
10
1
2
3
4
5
