Automatic power-off
As a default the instrument will be set to automatically turn itself off after
10 minutes without any action. Follow the steps below to turn the Auto-
Power Off function off.
1. Be sure the meter is powered off.
2. Press both the POWER and mA%/V buttons simultaneously. The
display will indicate the symbol ‘AP-XX’.
3. Press the button to activate or deactivate the Auto-Power Off
function. ‘AP-OF’ indicates that there is no automatic power-off
function set, and ‘AP-ON’ indicates the automatic power-off func-
tion is activated.
4. Turn the meter off to save the setting.
Outputs
The output terminal of the instrument can produce DC voltages set by the
user or simulating resistance.
! CAUTION
Do not apply any voltage to the output terminal during the
operation. If any improper voltage is applied to the output terminal, it will
cause damage to the internal circuits.
Output Operation Procedure
Function
Operation
Range
Operation
Display Set Range
DCA 20 mA 20 mA or %
00.000 mA
or
-025.00 mA %
00.000 to 22.000 mA
or
-025.00 to 112.50 mA %
