9. Adjustment Possibilities for the Model Car
a) Setting the Camber
Thecamberistheinclinationofthewheellevelasviewedfromthefront(vertical).
Negative inclination Positive inclination
(Topwheeledgepointsinwards) (Topwheeledgepointsoutwards)
 Thesettingofthewheelisexaggeratedinthetwoguresinordertomakethedifferencebetweennegative
and positive cambers more obvious. The setting on the model vehicle of course must not be as extreme as
shown!
• Anegativeinclinationofthefrontwheelsincreasesthelateralcorneringpowersofthewheelwhendrivingthrough
bends, the steering reacts more directly and steering forces are reduced. At the same time, the wheel is pushed onto
the axle spur in the direction of the axle. This reduces axial bearing clearance, the driving behaviour is calmer.
• Anegativeinclinationontherearwheelsreducesthetendencyoftherearofthevehicletoswerveinbends.
• Settingapositivecamberontheotherhandreducesthecorneringforceofthewheelsandshouldnotbeused.
Setting Front Axle Camber:
The "pivot ball" suspension at the front axis comprises of a
speciallyshapedaxisleg,twoball-headscrews(AandB)
andtwoouterplasticgrubscrews(C).
To setthe wheelcamber,theball-head screws(A) and
(B)aretwistedviaasmall2.5mmhexagonwrench(D)
thatispushedthroughtheholeofthegrubscrew(C)(see
next page).
Theplasticgrubscrews(C)canbetightenedorloosened
withaslightlylarger5mmhexagonwrench(E).However,
they only serve to fasten the axis stub to the ball-head
screws(A)and(B).
Nevertightentheplasticgrubscrews(C)byforce.Other-
wise, the wheel suspension cannot move freely. The plas-
ticgrubscrews(C)alsomustnotbeturnedintooloosely,
or the axis stub will wobble.
D
E
A
B
C
C
